Product Features

• Extreme Duty Motor - Increased performance through 60 minute duty rating, H4 classification, Class B insulation, cooling fins, and standard thermal motor protection. Offers higher horsepower than most competitors.
• External Motor Fan - Functions to quickly eliminate motor and brake heat. This results in improved hoist duty rating and greatly lengthens brake life.
• Pull-Rotor Motor Brake - Extremely durable and reliable, this advanced design contains no brake coil to fail like conventional disc brakes.
• Compact Aluminum Body - Die-cast body is lightweight and offers low headroom — one of the best in the industry. Paint is electrostatically applied.
• Durable Push-Button Pendant - Easy to use, one-handed operation. Rated IP65. Standard control voltage is 110V. Strain relief wire is molded to pendant cord for added support and dependability.
• Forged Carbon Steel Hooks - Under excessive loads will open gradually and not fracture. Ball bearings produce smooth rotation. Bottom hook will swivel 360 degrees. Heavy-duty hook latches are standard.
• Unique Chain Guide - Provides quiet and smooth guiding of chain. Easily replaced without disassembly of hoist. Heavy cast iron construction for improved wear versus stamped steel design offered by many manufacturers.
• Load Sheave - Deep-groove pockets fully support the load chain during operation. Reduces vibration and chain wear and provides a true vertical lift.
• Long Life Friction Clutch - Protects hoist from damage and prevents overwinding. ER Series couples Weston-style load brake with friction clutch.
• Completely Sealed Body - Suitable for both indoor and outdoor applications, including harsh environments. Gaskets throughout the hoist provide for an IP55 rating.
• Heat Treated Helical and Spur Gears - Precision machined for long life. Oil bath lubrication results in a quiet, smooth, cool operation.
• Count Hour Meter - This maintenance feature, supplied as standard on the ER Series hoists, tracks motor starts, running time and usage history by instant digital display. Meter operates independently of the hoist.
• Easy Maintenance Control Panel - Simple layout of controls and a single swing-out panel. Hinged controller cover provides standard wiring diagram and allows fast on-site access.
• Plug-In Connections - Saves valuable time on setup and maintenance. “Quick disconnect” replaces typical competitive hard-wired designs.
